| Item | Specification | Remarks |
|---|---|---|
| Typical Capacity | 30Ah | 0.5C discharge |
| Minimum Capacity | 29Ah | 0.5C discharge |
| Nominal Voltage | 76.8V | - |
| Discharging Voltage (Min) | 66V | - |
| Charging Voltage (Max) | 87.6V | - |
| Charging Current (Std) | 6A | 0.2C(0 ~ +45°C) |
| Discharging Current (Std) | 6A | 0.2C(-20 ~ +60°C) |
| Max Charging Current | 30A | 1.0C(0 ~ +45°C) |
| Max Peak Discharging Current | 90A | 3.0C(-20 ~ +60°C), 3s |
| Max Continuous Discharging | 60A | 2.0C(5 ~ +45°C) |
| Internal Impedance | ≤3.0mΩ | AC Impedance 1kHz |
| Cell Weight | Approx 21kgs | - |
| Storage Temp (< 1 Month) | -20 ~ +60°C | - |
| Storage Temp (< 12 Month) | -20 ~ +25°C | - |
